OH - 312+
Position: Drive

OH - 312+
Drive
Drive axle tyre for off road applicationsAggressive tread pattern that delivers outstanding traction in tough conditions with deeper and wider grooves that increase mileage and enhance service life.
Large Lugs, cut & Chip resistance compound withstand serve conditions in gravel /Construction Usage.
Open shoulder design that ensures quicker evacuation of water delivering good road grip specially designed sipes on tread blocks ensure snow performance.
Specification
Size | PR | Load Index | Speed Symbol | Maximum Load | Maximum Load | Max. Inflation Pressure | Rim Width | Section Width | Overall Diameter | Tread Depth |
![]() |
![]() |
![]() |
EPREL Link |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Single (kgs) | Dual (kgs) | psi | inches | mm | mm | mm | ||||||||
13R22.5 | 18 | 156/150 | K | 4000 | 3350 | 125 | 9.75 | 328 | 1130 | 22.0 | E | A | 75dB/B | View label |
315/80R22.5 | 20 | 156/150 | K | 4000 | 3350 | 125 | 9.0 | 314 | 1095 | 22.0 | D | A | 75dB/B | View label |
Regrooving Guidelines
Size | D. Regrooving Depth (mm) | W. Regrooving Depth (mm) |
---|---|---|
13R22.5 | 2.5 | 7.0 - 8.0 |
315/80R22.5 | 2.5 | 7.0 - 8.0 |
